Our company produces various types of indoor full color display. Using ultra-high brightness LED, so that you can see clearly from a long distance even in strong sunshine; showing more colorful display, high saturation high-resolution and high frequency dynamic image display; using nonlinear correction technology, distributed scanning technology and module design technology , making the diversification of the display mode and the operation is very convenient. The indoor single color display uses the module production which has high brightness, uniform color, rich color, high reliability and long life span.
The list of available Models of our LED display/screen/panel/sign
PH4mm,4.75mm,5mm,6mm,7.62mm,8mm,10mm,12mm,12.5mm,14mm,16mm,18mm,20mm,25mm,31.25mm,P37.5mm,40mm,100mm,125mm
1.Wide application field & short ROI time:
commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media, shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen, air port LED display screen, telecommunication LED display screen system for information showing and instruction
2. High Contrast ratio: 4000:1
Which is a very high level to ensure a vivid image of our LED display screen system.
3. First-class LED chip:
Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display screen system
4. Clear vivid image quality:
Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's investment.::
5. Long-term Brightness:
7000-nit brightness (for outdoor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display screen.
6. Easy Installation & Using:
easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system
7. Convenient Servicing:
Front and rear cabinet access makes the maintenance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.
| Pixel Configuration |
2R,1G,1B |
| Virtual/Visual pixel pitch(mm) |
8 |
| Physical/Real pixel pitch(mm) |
16 |
| Pixel density(dots/SQM)(Virtual/Visual) |
15625 |
| Pixel density(dots/SQM)(physical/real) |
3906 |
| Calibrated Brightness |
7500 nits(adjustable) |
| Color temperature |
3,500° — 9,500° K(adjustable) |
| Contrast ratio |
4,000:1 |
| Brightness Adjustment |
100 grade auto-adjustment |
| View angle(degree)(50% brightness) |
Horizontal: 120° (80° off center); Vertical: 70° (+25°/-45° off center) |
| Color Capability |
4.4 trillion |
| Refresh rate(Hz) |
>2400 Hz |
| Frame frequency(Hz) |
>60 Hz |
| Interface port |
DVI interface(DVI connector) |
| Input signal |
Video: PAL/NTSC Optioned: VGA, video, DVD,TV |
| Protection grade |
IP65 front side/IP54 backside |
| Operating temperature(Celsius degree) |
-20~+55' |
| Storage temperature(Celsius degree) |
-30~+55' |
| Operation Humidity(RH) |
0-95% |
| Storage Humidity(RH) |
0-99% |
| Lifetime(hours)(50% brightness) |
100,000 hours |
| Servicing |
Front and Back |
| Power supply |
100-240V/50-60HZ |
| Screen Operation mode: static |
1 |
| LED Drive |
constant-current drive |
| Power consumption(W/SQM):Maximum |
1094 |
| Power consumption(W/SQM):Average |
438 |
